ROTEX 200.10 SS TAS

Rubber Expansion Joint with PTFE lining and PTFE vakuum support ring

Camlock cam locking couplings:

Attachment AVB dust plug with chain to Spannloc clamps (service free of charge)

LNG ship bunkering

DCC 100 Dry Cryogenic Coupling, CBC 100 PERC Cryogenic Breakaway Coupling

Aircraft refuelling Hose Reel

rewind

Fluorflex FXD universal hose assemblies

with inner corrugation for maximal flexibility. Picture 1

Hot bitumen hose - loading (bunkering) ship

HB 100 hose assembly

Hose assemblies

for saturated steam, chemicals, petroleum based products

DEC – Dry Evotek Coupling

Dry disconnect coupling for the chemical industry

Bunker boat: HD hose assembly on reel, ZV 500 nozzle

Hose Reel Spring Rewind, ZVA Slimline 2 blue

ZVF 50 UL 91 / green

Manual aviation fuelling nozzle for overwing service. Flowrate up to 400 ltr. / min. (85 IGM – higher flowrates are possible). Size DN 50. Working pressure PN 10 (140 psi). Temperature range - 40° C up to + 55° C.

Oasis ball valves for CNG in winter

Polypal Clean hose assembly

Pharmaceutical production

Elapharm EPH 25 with foodstuff fitting DIN 11551, free of dead spaces

Universal hoses UTL with DDC Dry Disconnect Couplings

VB 80 SSE

TW dust plug of stainless steel, surface in contact with the medium additionally coated with Teflon® PFA. This type is used if stainless steel does not have a sufficient chemical resistance (i.e. for hydrochloric acid and iron-III-chloride) and polypropylene is not possible because of insufficient stability. Available in all standard sizes.

ZVA 25 spout with stainless steel tip

Cargo loading of a tanker with petroleum based products; FHD hose assembly with new longitudinal stripe to avoid torsion

Picture courtesy of Macoil International, Gibraltar

Camlock couplings:

stainless steel female and male couplings to EN 14420 - 7

ZVA Slimline 2 LA nozzle with LeverAssist hold-open aid

and Slimline dispensing hose, yellow

Manifold at petroleum storage terminal

STW 150 hose assemblies, SFC 150.16 hose flanges

SG 1" 1x0 Al

Sight Glass with propeller, to EN 13617-1, DN 25, for installation between petrol station nozzle and hose assembly, or mounting on the dispenser. For the visual control of bubble-free dispensing and fuel colour (e. g. for premium fuels). Suitable for all standardised gasoline and diesel fuels according EN 589 + EN 590, including ethanol or biodiesel content, also Avgas and Jet-A1.

Ship bunkering

FHD hose assembly, flange connection

MK 80-90 SS; MK coupling stainless steel with bent lever 90°

TW coupling with bent lever: For any application it should be checked that the lever can be arrested as shown even if there is tight space. Elaflex offers bent levers for all MK couplers.

Alternative fuels: B 20 (Diesel with up to 20% Biodiesel), E 85 (Gasoline with up to 85% Ethanol)

ZVA Slimline 2, ZVA Slimline 2 GR

TW coupler MK 80 SS-90° (bent lever) and dust plug VB 80 ADR SS with pressure relief

Slimline 16 blue

Quality petrol pump hose for gasoline and diesel fuels. Also suitable for fuels with ethanol content up to E 85 and Biodiesel up to B 30 (BIO Type up to B 100). Meets weights and measures regulations, see overleaf. Cold flexible down to - 30° C / - 22° F (LT-type down to - 40° C / - 40° F). Corresponds to EN 1360.

Vehicle refuelling with LPG (L.P. Gas, Autogas)

ZVG 2 DISH nozzle

Cabinet of road tanker:

MK 80-32 TW coupler with bent lever, VB 80 P dust plug

Camlock hose couplings: system comparison

Easyloc from Elaflex with automatically secured levers.
